Product Gallery

Tube & fin design:

Plate/bar and fin design:

Core construction (depth) 50 to 150 mm and by using modules up 240 mm;
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Flat top fin height 7, 10 & 12 mm;
Turbulator height from 1.6 to 4 mm.
Maximum core size 240 x 1000 x 1600 mm including the modules option;
Special core construction can be accommodated;
All heat exchangers capacity and size is determined based on customer specifications ;
All fitting and connecting points or mounting supports are made to customer specifications;
Reduced weight – all aluminum construction;
Improved corrosion resistance by using state of the art materials (long-life) and latest available CAB system brazing process;
One year warranty.

Plate & fin design:

Core size range for oil cooler cooled by water (2 to 22 plates) x (331 to 348 mm) x (36 to 81 mm)
Core size range for oil cooler cooled by air (45 to 95 mm) x (158 to 737 mm) x 900 mm.
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Flat top fin height 7, 10 & 12 mm;
Turbulator height from 1.6 to 4 mm.

Tube & fin design:

Tube construction (depth) maximum of 50 mm
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Flat top fin height 7, 10 & 12 mm;
Maximum dimensions of one heat exchanger module are 50 mm x 600 mm x 600 mm, larger sizes could be manufactured by using modules.

Plate/bar and fin design:

Core construction (depth) 32 to 240 mm;
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Flat top fin height 7, 10 & 12 mm;
Turbulator height from 1.6 to 4 mm;
Maximum dimensions of one heat exchanger module are 240 mm x 1000 mm x 1200 mm, larger sizes could be manufactured by using modules;
Special core construction can be accommodated;
High operating pressure (approx.1000 psig);
Heat exchanger capacity and size determined based on customer specifications;
All fitting and connecting points or mounting supports are made to customer specifications;
Reduced weight – all aluminum construction;
Improved corrosion resistance by using state of the art materials (long-life) and latest available CAB system brazing process;
One year warranty.

Tube & fin design:

Tube construction (depth) 36.5, 50, 62 & 70 mm;
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Flat top fin height 7, 10 & 12 mm;
Maximum dimensions of one heat exchanger module are 150 mm x 1000 mm x 1100 mm, larger sizes could be manufactured by using modules.

Plate/bar and fin design:

Core construction (depth) 32 to 240 mm;
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Flat top fin height 7, 10 & 12 mm;
Maximum dimensions of one heat exchanger module are 240 mm x 900 mm x 1000 mm, larger sizes could be manufactured by using modules;
Special core construction can be accommodated;
Heat exchanger capacity and size determined based on customer specifications;
All fitting and connecting points or mounting supports are made to customer specifications;
Reduced weight – all aluminum construction;
Improved corrosion resistance by using state of the art materials (long-life) and the latest available CAB system brazing process;
One year warranty.

Tube and fin construction;
Tube constructions (depth) 18 and 22 mm;
Maximum core size 600 x 800 mm;
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Parallel flow-best performance design for optimal thermal performance;
Special core construction can be accommodated;
Heat exchanger capacity and size determined based on customer specifications;
All fitting and connecting points or mounting supports are made to customer specifications;
Reduced weight – all aluminum construction;
Improved corrosion resistance by using state of the art materials (long-life) and the latest available CAB system brazing process;
One year warranty.

Core construction (depth) 32 to 240 mm;
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Flat top fin height 7, 10 & 12 mm;
Turbulator height from 1.6 to 4 mm;
Maximum dimensions of one combined cooling package are 240 mm x 1500 mm x 1500 mm.
Special core construction can be accommodated by jointing the heat exchangers together mechanically or by weld as follows:
- radiator + charge air cooler + oil cooler + A/C condenser;
- radiator + charge air cooler + fuel cooler + power steering cooler, etc.
- hydraulic + transmission + engine oil cooler, etc.
Heat exchanger capacity and size determined based on customer specifications;
All fitting and connecting points or mounting supports are made to customer specifications;
Reduced weight – all aluminum construction;
Improved corrosion resistance by using state of the art materials (long-life) and the latest available CAB system brazing process;
One year warranty.

Aluminum tube and fin, plate & bar and shell & tube copper - brass construction (fuel, power steering and engine coolers);
Tube constructions (depth) 18 and 22 mm or core construction (depth) 32 to 240 mm;
Aluminum serpentine tube & fins construction (single and double tubes);
Maximum core size 240 mm x 1000 mm x 1200 mm;
Louvered fin height 8, 9 and 12 mm;
Wavy non louvered fin height from 3 to 12 mm;
Special core construction can be accommodated;
Heat exchanger capacity and size determined based on customer specifications;
All fitting and connecting points or mounting supports are made to customer specifications;
Reduced weight – all aluminum construction;
Improved corrosion resistance by using state of the art materials (long-life) and the latest available CAB system brazing process;
One year warranty.

Radiators
